A-1149-2
STAINLESS STEEL WATERPROOF LOCK HANDLES
Catalogue View
| Product No. | RoHS | Remarks | Code | Ask Price | 2D | 3D |
|---|---|---|---|---|---|---|
| A-1149-2 |
|
02086 |
Features
- Fire-resistant, heat-resistant, saltwater-resistant and acid-resistant.
- These can be fixed to thick doors.(to 14mm)
- This product is equivalent for waterproof standard IPX5.(UsingO-ringandpacking)
- For both left-hand right-hand use.
Specifications
- Material: Stainless steel cast (SUS304)
- Finish: Main body: Beading process
Cover: Hairline finish - Protection class: IPX5
Specific Use
- Steel plate thick doors
Remarks
- No.0060-H·No.0061-H·No.0062-H are optional.
- It is recommended that thread-locking fluid be used to prevent loosening of the mounting screws for the catch.
