AP-469-W

MULTI LOCK FLUSH HANDLES

Catalogue View

MULTI LOCK FLUSH HANDLES
MULTI LOCK FLUSH HANDLES Spec Sheet
Product No. RoHS Remarks Code Ask Price 2D 3D
AP-469-W 04262

Request for Quote

Features

    • With two high-security TAK Series locks built in, can be set up in many different ways.
    • With standard setting, handle can be operated by unlocking either lock.
    • Other settings include enabling handle to be operated by unlocking both locks.
    • Made of durable glass-fiber reinforced resin.
    • Made of lightweight resin.
    • For both left- and right-hand use.

Specifications

    • Material: Polyamide (PA66-GF25)
    • Surface finish: Wrinkle finish (design surface)
    • Applicable panel thickness: 0.8 to 2.3mm
    • Accessories: Screw set, keys (number by arrangement)

Specific Use

    • Drug repository, precision medical equipment control board, etc.

Remarks

    • Not waterproof: recommended for indoor use.
    • It is recommended that thread-locking fluid be used to prevent loosening of the mounting screws for the catch.
    • Be sure to test adequately when using a solvent such as thread-locking fluid.
