C-300-MCU-T
SHIELDING TAPES (masking)
C-300-MCU-M
SHIELDING TAPES (masking)
Catalogue View
| Product No. | RoHS | Remarks | Code | Ask Price | 2D | 3D |
|---|---|---|---|---|---|---|
| C-300-MCU-T10 |
|
30m | 24341 | |||
| C-300-MCU-T13 |
|
30m | 24342 | |||
| C-300-MCU-T19 |
|
30m | 24343 | |||
| C-300-MCU-T25 |
|
30m | 24344 | |||
| C-300-MCU-M4 |
|
For M4 | 24345 | |||
| C-300-MCU-M5 |
|
For M5 | 24346 | |||
| C-300-MCU-M6 |
|
For M6 | 24486 | |||
| C-300-MCU-M8 |
|
For M8 | 24487 |
Features
-
C-300-MCU-T
- Tin-plated copper foil with masking tape.
- Saves you the trouble of applying conductivity treatments (plating or conductive coating) to a casing or housing.
- Following application, simply peel the masking tape away from the tin-plated copper foil surface.
- After masking tape removal, the tin-plated copper foil can be used as a conducting surface.
- Uses electrically conductive adhesive to minimize any shielding effect.
- Easy handling and application.
-
C-300-MCU-M
- Characteristics are the same as for C-300-MCU-T.
Specifications
-
C-300-MCU-T
- One roll: 30m
-
C-300-MCU-M
- One sheet: 10pcs
Specific Use
- Grounding/shielding for cases/housings
- Masks during painting and prevents casing corrosion.
- Can also be made as a cut product and in irregular shapes.
