BP-879
ROTARY DAMPERS
B-879
ROTARY DAMPERS
Catalogue View
| Product No. | RoHS | Remarks | Code | Ask Price | 2D | 3D |
|---|---|---|---|---|---|---|
| B-879-0-L-50K |
|
13008 | ||||
| B-879-0-R-50K |
|
13009 | ||||
| B-879-1-L-20K |
|
12701 | ||||
| B-879-1-R-20K |
|
12741 | ||||
| B-879-1-R-0K |
|
13223 | ||||
| BP-879-1-L-15K |
|
11471 | ||||
| BP-879-1-R-15K |
|
11472 | ||||
| BP-879-1-L-10K |
|
11825 | ||||
| BP-879-1-R-10K |
|
11826 | ||||
| BP-879-1-L-5K |
|
11827 | ||||
| BP-879-1-R-5K |
|
11828 | ||||
| BP-879-1-R-0K |
|
11829 |
Features
-
B-879
- Damper characteristic: Closing time 5±2.5 sec.
(Test method: freely drop from position 70° from horizontal) - Closing time 1.5 sec or longer is marked during an endurance test of 100,000 times closing. 〔BP-879-1・B-879-1〕
- The optimum damper characteristic can be obtained within the rotation range of 180°(in the arrow direction). (Rotation in the arrow opposite direction is no load.)
- Having designed as a compact hexagonal shape, setting of the product on the door can be readily made.
- Damper characteristic: Closing time 10±5 sec.
- Closing time 2.5 sec or longer is marked during an endurance test of 100,000 (normal temperature) times closing.
- 〔B-879-0〕
-
BP-879
- Damper characteristic: Closing time 5±2.5 sec.
(Test method: freely drop from position 70° from horizontal) - Closing time 1.5 sec or longer is marked during an endurance test of 100,000 times closing. BP-879-1・B-879-1〕
- The optimum damper characteristic can be obtained within the rotation range of 180°(in the arrow direction). (Rotation in the arrow opposite direction is no load.)
- Having designed as a compact hexagonal shape, setting of the product on the door can be readily made.
- Damper characteristic: Closing time 10±5 sec.
- Closing time 2.5 sec or longer is marked during an endurance test of 100,000 (normal temperature) times closing.
- 〔B-879-0〕
Specifications
-
B-879
- Material: Main unit: Zinc alloy (ZDC)
Shaft: Zinc alloy (ZDC)
-
BP-879
- Material: Main unit: Polyacetal resin (POM)
Shaft: Zinc alloy (ZDC)
Specific Use
- Hat racks and service boxes and trains
Remarks
- The hinge must not be installed vertically.
- Axial load must not exceed 49N.
- Working temperature range: 0 to +40℃
- B-879-1-R-0K can be used in either left or right turning direction.
- Within the range of the working angle, the stop-per must be installed in addition to the damper.
- The rated load torque does not represent the weight of a door.Calculate the torque applied to the dumper before use.
- Using exceeding the rated load torque may cause an oil leak or other problems.
- If an angle margin is used, any trouble such as oil leakage may be caused.
- Consult us, for further details.
